6
SLOT/MODE
REVERSE / BAD CELL / SHORT CIRCUIT
When 2 batteries are charging at the same time, press SLOT to
switch the display information (Battery Type, Charging Status,
Current, Voltage, Time) for next charging slot.
Reverse the battery polarity, incorrectly inserting the battery, inserting alkaline
battery or short circuit will result in charging failure, the “Error” icon will be shown
on the LCD display and capacity gauge for the corresponding slot will flash
rapidly. Should this occur, please reposition / replace / remove the battery from
the slot.
Initial charging current is 500mA for all supported type batteries.
Press MODE to switch between 500mA & 1000mA. (For Li-ion &
LiFePo4 ONLY).
To charge LiFePo4, press SLOT & MODE at the same time.
WARNING: If the charger loses power, the charge setting will reset. If the char-
ger auto-detects Li-ion but it is a LiFePo4, it may charge to the wrong voltage.
