8.1 PL600H/ PL1000H
8) Technical Characteristics
Motor
Gear type
Peak thrust
Nominal thrust
Power supply
Nominal input power
Maximum operating current
Maximum gate weight
Maximum gate length
Duty cycle
Operating Temperature
Dimension
Weight
Main power supply
Back-up battery
Transformer
Receiver board
24Vdc motor with mechanical release
Worm gear
6500N
6000N
24Vdc
2.5A
5.5A for maximum 10 seconds.
600 kg per leaf
8 meters
20%
-20℃~+50℃
333mm*216mm*287mm
10.2 kg
230Vac/50Hz, 110Vac/50Hz
2pcs of batteries for emergency
operation, 1.2A each, 1.1kg
6A, 24V
433.92MHz; 200 transmitters memory
24Vdc motor with mechanical release
Worm gear
10500N
10000N
24Vdc
2.5A
5.5A for maximum 10 seconds.
1000 kg per leaf
12 meters
20%
-20℃~+50℃
333mm*216mm*287mm
10.4 kg
230Vac/50 Hz , 110Vac/50Hz
2pcs of batteries for emergency
operation, 1.2A each, 1.1kg
11.4A, 22V
433.92MHz; 200 transmitters memory
PL600H PL1000H
8.2 PH-2 Photocells
Detection type
Operating distance
Response time
Input voltage
Operating Temperature
Protection class
Dimension
Through beam
25 meters
100ms
AC/DC 12~24V
-20℃~+60℃
IP54
96mm * 45mm * 43mm
8.3 PR-1 Radio Transmitter
Application
Frequency
Coding
Buttons
Power Supply
Operating Temperature
Dimension
PL600H/PL1000H
433.92Mhz
Rolling code
2, for single-gate or dual-gate operation
3V with one CR2032 button type lithium battery
-20℃~+50℃
71.5mm * 33mm * 14mm
8.4 PF-1 Flashing Light
Application
Lamp
Operating Temperature
Installation
Dimension
For warning purpose during leaves movement
24Vdc Halogens bulb
-20℃~+50℃
horizontally or vertically installed
205mm * 80mm * 75mm
8.5 PKS-1 Key Selector
Application
Installation
Operating Temperature
Dimension
For outdoor use
Wall mounted vertically
-20℃~+50℃
85mm*60.5mm*40.5mm
8.6 PPB-1 Push Button
Application
Installation
Operating Temperature
Dimension
For indoor use
Wall mounted vertically
-20℃~+50℃
85mm*60.5mm*40.0mm
