Powerware 3115 - UPS Rear Panels

Installation
6
Powerware
®
3115 User’s Guide S www.powerware.com
UPS Rear Panels
This section shows the rear panels of all Powerware 3115 models.
Power Cord with
5-15 Plug
Communication Port
DIP Switches
Two 5-15 Output
Receptacles
10A, Resettable
Circuit Breaker
Site Wiring Fault Indicator
Figure 3. PW3 300 and PW3 420 Rear Panel
Four 5-15 Output Receptacles
Communication Port
Site Wiring Fault Indicator
DIP Switches
10A, Resettable
Circuit Breaker
Power Cord with
5-15 Plug
Figure 4. PW3 650 Rear Panel
