User manual PowerXtreme X20/X30
E18-X20X30-EN00 www.emergoplus.com Page 11 of 25
▪ Capacity: Capacity/Content of the battery in Ah
▪ Status: Charging - Discharging – Standby
▪ Health: of the battery
▪ On/ Off On/ Off switch
SOC means "State of Charge" or the state of charge of the battery. The
voltage and capacity of the battery are listed below.
STATUS" shows whether the battery is charging or discharging or whether
the battery is in standby mode.
Health shows the condition of the battery. This varies from Perfect, Good
and Bad.
The three dots at the bottom right open a menu intended for service
purposes.
U.I.T.C. info tab:
Voltage meter Terminal voltage of the battery in V
Current meter Present current consumption in A
