User manual PowerXtreme X20/X30
E18-X20X30-EN00 www.emergoplus.com Page 12 of 25
Temperature Temperature of the battery cells
Cycle life Number of charge/discharge cycles
The UITC info shows 2 "meters", on the left the battery voltage and on the
right the current. This can be the charging current or the current drawn from
the battery. If the battery is connected to a charger but at the same time
power is requested by users, the resulting current is displayed.
Temperature of the cell pack. If the temperature is too low or too high, a
safety device is activated.
Cycle life keeps track of how often the battery has been discharged by 80%.
For example, from 90% SOC to 10% SOC is a cycle. Also, from 70% SOC to
empty then charging to 100% and empty to 90% is a cycle.
