Table 4.1 Burner Pressures - Natural Gas - Group H - G20 - Net CV (H
i
) = 34.02MJ/m³
Riello Burners
Start Gas Main Burner
Model Type Pressure Pressure Gas Rate
mbar mbar m³/h
CP-G 100 GS 5 N/A 4.3 3.40
CP-G 150 GS 10 N/A 4.2 5.12
CP-G 200 GS 10 N/A 3.7 7.08
CP-G 300 GS 10 N/A 5.2 10.89
CP-G 400 GS 20 2.4 5.0 14.14
CP-G 500 GS 20 3.4 6.3 17.86
CP-G 600 GS 20 2.4 5.3 21.39
CP-G 700 GAS 3 2.5 6.7 25.15
CP-G 800 GAS 3 1.1 7.8 28.20
CP-G 1000 GAS 3 3.3 9.4 35.25
CP-G 1250 GAS 5 0.75 8.2 43.78
CP-G 1500 RS 50 0.75 5.6 54.00
CP-G 2000 GAS 5 Refer to Powrmatic 71.82
Table 4.2 Burner Pressures - Propane Gas - G31 - Net CV (H
i
) = 88.0MJ/m³
Riello Burners
Start Gas Main Burner
Model Type Pressure Pressure Gas Rate
mbar mbar m³/h
CP-G 100 GS 5 N/A 3.1 1.31
CP-G 150 GS 10 N/A 6.4 1.98
CP-G 200 GS 10 N/A 4.1 2.74
CP-G 300 GS 10 N/A 8.3 4.21
CP-G 400 GS 20 2.5 5.9 5.47
CP-G 500 GS 20 3.7 8.5 6.90
CP-G 600 GS 20 3.1 8.9 8.27
CP-G 700 GAS 3 2.9 12.9 9.72
CP-G 800 GAS 3 3.0 18.2 10.90
CP-G 1000 GAS 3 2.5 17.5 13.62
CP-G 1250 GAS 5 2.8 18.0 16.92
CP-G 1500 GAS 5 2.8 18.0 20.43
CP-G 2000 GAS 5 Refer to Powrmatic 27.24
Table 5 Pump Pressures - 35sec Oil - Net CV (H
i
) = 42.69MJ/kg
Riello Burners
Nozzle Pump
Model Type Make Size Angle Type Pressure
° bar
CP-O 100 G5 Danfoss 0.60 80 S 14.3
CP-O 150 G10 Danfoss 1.0 60 S 12.2
CP-O 200 G10 Danfoss 1.25 60 S 12.9
CP-O 300 G10 Danfoss 2.0 60 S 13.6
CP-O 400 G20S Danfoss 2.5 60 S 13.6
CP-O 500 G20S Danfoss 3.0 80 H 14.3
CP-O 600 G20S Danfoss 3.75 60 B 14.3
CP-O 700 G20S Danfoss 4.5 60 B 13.6
CP-O 800 Press GBV Danfoss 5.0 45 B 14.3
CP-O 1000 Press GBV Danfoss 6.0 45 B 15.0
CP-O 1250 RL38 Danfoss 4.5 60 B 14.3
CP-O 1500
CP-O 2000 Refer to Powrmatic
Refer to Powrmatic
8
