HEMNVx & HEMSL Range Users, Installation & Servicing Instructions Doc Ref M103 issue 3.1 Feb 2018.
HEM-NVx Pressure Drop Graph
Note:
HEM NVx
The above data refers to a single module pressure drop. For twin models, refer to manufacturer.
