Powrmatic LX Series User Manual

page no. 45 of 68
LX Range Users, Installation & Servicing Instructions Doc Ref M110 issue 1.0 Dec 2020.
Volt Free
Ignition Lockout circuit
Volt Free
Burner On circuit
12-24Vdc Fan only
1 sec pulse L/O Reset
OV GND
2.4.6.6 LX Modulation BMS Interface Interconnections (Option 2)
12-24Vdc Heat Enable
*Option 2 requires a HEAT ENABLE signal from the BMS
O-10Vdc Modulation
Inputs from BMS
Input from BMS
* BMS Interface Boards will be factory
fitted and attached to the outside of
the heater.
2.5 Wiring Diagrams
