2.7 Servicing
3. Fit replacement in reverse order.
2.7.7.8. R2R Main Control Board
1. Unplug all the electrical connections by squeezing each
side to release.
2. Using a small flat screwdriver push on the locking tab
of each PCB mount and gently ease the board upwards to
release.
Note: Each control board is pre-programmed
to specific heater kW sizes. Ensure the correct
board is fitted (see following table)
Model
Part number and config no.
LX15 142400360-001 001
LX20 142400360-002 002
LX25 142400360-003 003
LX30 142400360-004 004
LX35 142400360-005 005
LX40 142400360-006 006
LX50 142400360-007 007
LX60 142400360-008 008
LX70 142400360-009 009
LX90 142400360-010 010
LX120 142400360-011 011
LX140 142400360-012 012
3. Fit replacement in reverse order.
2.7.7.9. Thermistor
1. Disconnect the thermistor from the exhaust fan outlet
2. Disconnect the two pin plug and socket connected
to the end of the red/white cable situated behind the
electrical chassis plate
3. Fit replacements as appropriate and reassemble in
reverse order..
2.7.7.10. Run/Fault Indicator Lamp
Situated at the bottom of the front panel.
1. Disconnect the electrical plug from the R2R board
2. Squeeze and pop out the indicator bezel from the front
panel
3. Fit replacement as appropriate and reassemble in
reverse order..
2.7.7.11. Centrifugal Fan/Motor
1. Disconnect the electrical connections to the centrifugal
fan section.
2. Remove the side panels of the section for access to the
fan and motor.
3. Fit replacements as appropriate and reassemble in
reverse order.
Note: If a 3ph motor is being replaced ensure
that the direction of rotation is correct. If it is
not interchange any two of the three phases
connected to the motor.
2.7.7.12. Filters
Heaters fitted with an inlet filter box.
1. Remove screws fixing filter box side cover and lift away
cover.
2. Withdraw original filters from the sliders.
3. Fit replacement as appropriate and reassemble in
reverse order.
