Powrmatic LX Series User Manual

page no. 7 of 68
LX Range Users, Installation & Servicing Instructions Doc Ref M110 issue 1.0 Dec 2020.
Dimensions
LX F- Freeblowing
Model 15 20 25 30 35 40 50 60 70 90 120 140
A
mm
997 997 997 997 1325 997 1325 1325 1325 1950 1950 1950
B
mm
730 730 730 730 819 730 819 819 819 819 819 819
C
mm
450 500 570 670 532 720 684 760 912 810 975 1140
DØ
mm
80 80 80 100 100 100 100 130 130 130 130 130
E
mm
268 268 268 268 357 268 357 357 357 337.5 337.5 337.5
F
mm
200 248 318 396 170 446 320 325 476 457 622 787
G
mm
120 120 120 142 142 142 142 220 220 220 220 220
H
mm
317 317 317 317 347 317 347 347 347 347 347 347
J
mm
450 450 450 450 700 450 700 700 700 662.5 662.5 662.5
K
mm
230 230 230 230 278 230 278 278 278 278 278 278
L
mm
859 869 819 834 918 834 938 915 915 938 915 915
M
mm
217.5 217.5 217.5 217.5 247.5 217.5 247.5 237 237 247 247 247
N
mm
117 117 117 117 145.5 117 145.5 145.5 145.5 90 90 90
P
mm
185 172 245 219.5 144 285 221.5 298 373.5 412 413 481
Q
mm
115 125 75 90 85 90 105 82 82 105 82 82
R
mm
137 137 137 137 181.5 137 181.5 181.5 181.5 181.5 181.5 181.5
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
A A
B B
C C
D D
E E
F F
"Title Here"
LX F - Freeblowing Units
SCALE: 1 : 12SHEET 1 OF 1
"Description Here"
"Material Gauge & Spec Here"
ISSMODIFICATIONSDATEDCRI/ADRN
UNSPEC. TOLS.
Hole centers
±0.1mm
General ±0.1mm
Finished sizes ±0.1mm
MM
DO NOT SCALE
This drawing is copyright and the property of POWRMATIC
LIMITED. It must not be used without their knowledge, nor
communicated to any other person or company.
Powrmatic Ltd. Hortbridge, Ilminster. Somerset.
TA19 9PS.
Tel: 01460 53535 Fax: 01460 52341
Web: www.powrmatic.co.uk E mail: r&d@powrmatic .co.uk
POWRMATIC LTD
01
NEW DRAWING06/01/2021
--
chrisbromfield
TITLE:
DESCRIPTION:
DRAWING NUMBER:
MATERIAL GAUGE & SPEC:
SALVAGNINI:
MATERIAL REQUIRED:
PROJECTION:
UNITS:
A
C
14 B
Q
L
N
M
M
M
P
F
G


D
K
J CRS
H
R
2
2
8
.
0
C
R
S
2
2
8
.
0
C
R
S
R
E
G
R
2
2
8
.
0
C
R
S
2
2
8
.
0
C
R
S
R
K
J CRS J CRS
H
E
G
SUSPENSION POINTS M10
SUSPENSION POINTS M10
GAS ENTRY POINT
ELEC ENTRY
50.0
1
9
7
.
0
