Powtran PI500A Series User Manual

7 / 16
terminal 2
control), the terminal can be used to decelerate the inverter until stop, at
the time the deceleration time is fixed for deceleration time 4.
49
Deceleration DC
braking
If the terminal is valid, firstly the inverter decelerates to the initial
frequency of stop DC braking, and then switches directly to DC braking
status.
50
Clear current running time
If the terminal is valid, the inverter's current running time is cleared
F1.10
Terminal command mode
0: Two-wire type 1;
1: Two-wire type 2;
2: Three-wire type 1;
3: Three-wire type 2
0
★
F1.11
Terminal UP / DOWN change rate
0.001Hz/s to 65.535Hz/s
1.000Hz/s
☆
F1.12
Minimum input for AIC1
0.00V to F1.14
0.30V
☆
F1.13
F1.12 corresponding setting
-100.0% to +100.0%
0.0%
☆
F1.14
Maximum input for AIC1
F1.12 to +10.00V
10.00V
☆
F1.15
F1.14 corresponding setting
-100.0% to +100.0%
100.0%
☆
F1.25
AI input setting selection
Units digit:AI1 Below the minimum input
setting selection
0: Corresponding to the minimum input set;
1:0.0%;
000
☆
F1.26
HDI Minimum input
0.00kHz to F1.28
0.00kHz
☆
F1.27
F1.26 Corresponding to the set
-100.0% to +100.0%
0.0%
☆
F1.28
HDI Maximun input
F1.26 to 100.00kHz
50.00kHz
☆
F1.29
F1.28 Corresponding to the set
-100.0% to +100.0%
100.0%
☆
F1.30
DI filter time
0.000s to 1.000s
0.010s
☆
F1.31
AI1 filter time
0.00s to 10.00s
0.10s
☆
F1.34
HDI filter time
0.00s to 10.00s
0.00s
☆
F1.35
DI terminal Mode Selection 1
Units digit:DI1 :
0:High level active; 1: Low level active
Tens digit: DI2(Same as the units digit);
Hundreds digit:DI3(Same as the units digit)
Thousands digit:DI4 (Same as the units digit);
Ten thousands digit:DI5(Same as the units digit)
00000
★
F1.36
DI terminal mode selection 2
Units digit:DI6 ;
0:High level active; 1:Low high level active
00000
★
F1.37
DI1 delay time
0.0s to 3600.0s
0.0s
★
F1.38
DI2 delay time
0.0s to 3600.0s
0.0s
★
F1.39
DI3 delay time
0.0s to 3600.0s
0.0s
★
F1.40
Define the input terminal repeat
0:Unrepeatable; 1:Repeatable
0
★
F2 group Output terminal parameter set
Code
Parameter name
Setting range
Factory
setting
Cha
nge
F2.02
Relay 1 output function selection (TA1.TB1.TC1)
0 to 39
2
☆
F2.04
SPA output function selection (Collector open circuit
output terminals)
1
☆
The functions of the relay and SPA output terminal are described as follows:
Set
value
Function
Functional Description
0
No output
Output no action
1
Frequency inverter
operation
Frequency inverter is operation, there is output frequency,(Can be 0)
there is output signal
2
Fault Output (Fault
outage)
When the frequency inverter fails and the fault stops, the output.Is
ON signal
3
Frequency Level
detection FDT1 output
Please Refer function code F7.23, F7.24
4
Frequency arrival
Please Refer function code F7.25
5
Zero-speed operation (No
output when shutdown)
When the frequency inverter runs and the output frequency is 0, the
output signal is ON. The signal is OFF when the converter is down.
6
Motor overload
forecasting alarm
Before motor overload protection action, the output is ON signal,
after the threshold value of overload warning is exceeded. For motor
overload parameter setting, refer to function codes F8.02-F8.04.
7
Frequency inverter
overload forecasting
alarm
The output signal ON 10 seconds before the overload protection
occurs.
8
Set count value to arrival
When the count value reaches the value set by E0.08, the output
signal is ON
9
Designated count value
arrives
When the count value reaches the value set by E0.09, the ON signal
is output. Counting function reference E0 group function description
10
Length arrival
When the actual length of detection exceeds the length set by E0.05,
the output signal is ON.
11
PLC cycle completed
When a simple PLC completes a cycle, it outputs a pulse signal with
a width of 250ms.
12
Accumulated runtime
arrival
When the accumulative running time of the converter exceeds the set
time of F7.21, the output signal is.ON
13
Frequency limiting
When the set frequency exceeds the upper or lower limit frequency,
and the output frequency of the frequency inverter also exceeds the
upper or lower limit frequency, the output signal is ON
14
Torque limiting
In the speed control mode, when the output torque reaches the limit
value of the torque, the frequency inverter is in stall protection state
and transmits ON signal at the same time.
15
Operational readiness
When the power supply of the main circuit and control circuit of the
frequency inverter is stable, and the frequency inverter does not detect
any fault information, and the frequency inverter is in the operational
state, the output signal is ON
17
Upper limit frequency
arrival
When the operating frequency reaches the upper limit frequency, the
output signal is ON.
18
Lower limit frequency
arrival (No output when
down)
When the operating frequency reaches the lower limit frequency, the
ON signal is output. The signal is OFF in downtime.
19
Under voltage state output
When the frequency inverter is under-voltage, the output signal is ON.
20
Communication settings
Please refer to the communication protocol.
23
Zero speed operation 2
(Output when down)
When the output frequency of the inverter is 0, the ON signal is output.
The signal is ON when the machine is down.
24
Accumulated power-on
time arrives
When the accumulative power-on time of the frequency inverter
(F6.08) exceeds the set time of F7.20, the ON signal is transmitted.
25
Frequency level
detection FDT2 output
Please refer the function code description F7.26, F7.27
26
Frequency 1 arrival ouput
Please refer the function code description F7.28, F7.29
27
Frequency 2 arrival output
Please refer the function code description F7.30, F7.31
28
Current 1 arrival output
Please refer the function code description F7.36, F7.37
29
Current 2 arrival output
Please refer the function code description F7.38, F7.39
30
Timed output
When the timing function selection (F7.42) is effective, the ON signal
is output after the frequency converter reaches the set timing time.
31
AI1 input overrun
When the value of analog input AI1 is greater than F7.51 (Upper limit
of AI1 input protection) or less than F7.50 (Under AI1 input
protection).The ON signal is output.
33
Reverse operation
Converter in reverse operation, output ON signal
