Powtran PR5300 User Manual

Chapter 5 Control panel and operation
14
Code Setting Description
Code
Name
Range of
set value
Factory
setting
Explanation
limit
PP
Motor rated current
11-998A
Rated
value
Used to input motor nominal is rated
current.
PU
Bypass delay
0-40S
3S
Used to set the delay time of Bypass
PL
Allowed three-phase
imbalance
0 or 1
1
0:Forbid,1:Allow
PM
Current regulation rate
50-150%
100%
Used to adjust the display of current.
PN
Voltage regulation
rate
50-150%
100%
Used to adjust the display of voltage.
Note:
1.The load regulation of P6 is based on PP calculated sustainable operation of the maximum
current according to the light and heavy of the load, above this value will do inverse time thermal
protection.
2.It will automatically exit the setting mode, if no key operation is more than 2 minutes
during setting state.
3.It’s not allowed to set parameters in the soft start and soft stop process..
4.Pressing the Set key (PRG) when powered on the soft starter, can default the parameters to
factory setting.
5-3.Programmable relay output functions
There are two programmable relay output function, programmable timing output way and
programmable state output way.
5-3-1.PE set from 0 to 4 items (10 ~ 14), programmable output work is timing output way, the
setting of output starting time as tabled below:
PE setting
value
0(10)
1(11)
2(12)
3(13)
4(14)
Programming
output time
Initiate action
command
Starting at the
beginning
Bypass
operation
Stop action
command
Stopping is
complete
5-3-2.PE is from 5 to 9 (15 ~ 19), the programmable output work is state output mode, the
setting of the working state output as tabled below:
PE set value
5(15)
6(16)
7(17)
8(18)
9(19)
State of output
indication
Motor fault
conditions
Running
Preparation
state
Start state
Bypass state
(1)Programmable state output to indicate the working state of the soft starter, the time set by
P4 is invalid in this mode. The factory setting of PE is 7, which indicates the preparation state of
soft starter, can start the motor in this state; programmable output is in the failure state, which
indicates the fault of the motor (Err05, Err06, Err07, Err08, Err12, Err15), which is different from
the function of ⑤, ⑥ fault output terminals; running state refers to non preparation or fault
condition, which includes 3 process of start, bypass, soft-stop.
(2)When PE> 9, the reset state of the programmable output (③, ④ No. External pin) changed
from normally open to closed, that is inverted output. Flexible using the function of programmable
relay output, which can effectively simplify the external control logic circuit.
5-4.The electrical terminal running protection functions
The functions divided into two states and they can be chosen by jumper mode
State 1:The electrical terminal running protection is valid: The external control terminal is on
