Powtran PR5300 User Manual

Chapter 3 The conditions of use and installation requirements
5
150mm
more than
150mm
more than
Air
OUT OUT
In In
150mm
more than
Figure 3.3 Figure 3.4
Installation requirement for PR5300G3 132-500kW
3-3.The appearance and installation dimension of the soft starter
PR5300 series 132kW-500kW soft starter appearance and installation dimensions are as
follows. PR5300 series 132kW-500kW soft start, its factory standard configuration for three-six.
The rated power and rated current is max rated value of soft starter. Usually, matching the
corresponding parameter of motor shall not be more than this value.
Shape and mounting dimension for PR5300G3 11-115kW:
H1
H
W
d
a
b
L
