Poynting MIMO-3-V2 - Page 10

10 A-MIMO-0003-V2_PCL
Installation Instructions
5
• Place the antenna at the highest point possible
and ensure that there aren’t any surrounding
obstructions to the antenna.
• In order to avoid communication interference,
ensure that the antenna is placed at least 0.5m
away from other antennas and metal objects.
• Avoid installing the antenna near a chimney,
as the smoke and soot emitted by the chimney
can obstruct the signal level achieved by the
antenna.
• Install the antenna away from heat sources and
ammable gases.
Antenna Mounting Precautions
6
Optional magnetic base kit
Antenna
Adhesive
foam seal for
Adhesive
installation
Metallic Surface or Magnetic
surface for Optional Magnet
Base kit installation
RF Cable
6 x Magnetic Discs
6 x M4 x8mm
Stainless Steel screws
Non scratch rubber
Adhesive discs
