CD30/35 QUICK START ADDENDUM
1 – SETUP WIRING
• Incoming power (230v)
o In enclosure: L1=35, L2=36, GND=38
o Open chassis: L1=31, L2=32, GND=38
• Outgoing power: L1=41, L2=42, GND=43
• PPM feedback sensor: black=1, red=3, white=12, Large black=16
• Manual run jumper between 5 & 6
2 – INITIAL SETTING SETUP
• Set C127, EnS=1 (Unhide the service menu)
• From the defaults change the following parameters:
o Menu C038
 I=100
 A=0
 P=10
o Menu C040
 SPE=0
 APS=1
• Set C051=25
o Change by adjusting the sensor position
o This setting can be ignored if using the blue sensor
3 – TEACH THE NATURAL OPERATING FREQUENCY
• Push the green ON button (start the controller)
• Go to C038, AFS, press up arrow (to start the frequency search)
• NOTE: When successful screen will return to the root menu.
4 – SET OPERATING CHARACTERISTICS (A & P)
Set A & P so that the maximum conveyor stroke is achieved when A=100
• Push the red OFF button (stop the controller)
• In C038 set A=100 & P=10
• Push the green ON button (start the controller)
• Gradually increase P (until the required maximum amplitude of the feeder is reached)
• Once P is set, A can be used to adjust the amplitude to control capacity
throughput
5 – SAVE USER SETTINGS & HIDE MENUS
After setting up the controller: hide C038 & C040, save user settings
• Set C127, EnS=0 (hides the C040 service menu)
• Go to C143, PUSH, press up arrow (saves all settings under the user settings
memory)
