PPM CD30 - 1.1 Controller Specifications; 1.2 Application

P/N SM1222
Rev 6
Print Date 2/14/2018
1 – SUMMARY
The CD30 with software version “L” or higher is compatible with both Wright LT
conveyors and PPM VF & Magnatron conveyors. The main changes from the DMT include:
• The CD30/35 runs about half as quiet (10dbA less) as the DMT
• All settings are made by using the touch-panel and display (similar to a VFD touch-
panel) that is incorporated into the front panel of the CD30
• The CD30/35 does not come standard with a door potentiometer
• The CD30/35 does come with a local disconnect switch mounted onto the door
• The CD30/35 works as a replacement for both the DMT & MagII controllers, and will be
phased in PPM’s new standard controller for all applications for the above legacy
controllers.
1.1 – CONTROLLER SPECIFICATIONS
• Supply voltage: 115/230 v, +/-15%, 50/60 Hz
• Supply Power Draw: 3 to 4A
• Set Point: display, potentiometer 10kOhm, 0-10vdc, 0(4)-20mA
• Enable Input: contact, 24vdc
• Enable 2
nd
Setpoint: contact, 24vdc
• Status relay: change over contacts (max 250v, 2A)
• Fuse: 10A, Type B
• Operating Temperature: 0°C to 45°C
1.2 – APPLICATIONS
The CD30/35 has been tested & validated to work on the following equipment:
• VF Advance & Mini at 1200cpm (20hz) to 1450cpm (24.2hz)
• VF Premier & VFX at 750cpm (12.5hz) to 1200cpm (20hz)
• Magnatron at 1500cpm (25hz) to 2100cpm (35hz)
NOTE: CD30/35 will virtually work at any speed from 5hz to 60hz on all equipment, with or
without a feedback sensor. The above equipment speed ranges are just guidelines for our
typical equipment.
There are two sizes of CD30/35 Controller, a 10A & a 15A controller. The controller required is
base on the rules below regarding the application & product density:
• Use the CD30 (10A controller) if:
o Product density is 20lb/ft^3 or less
• Use the CD35 (15A controller) if:
o Product density is greater than 20lb/ft^3, or
o The conveyor is being fed by a hopper
