2.1 – POWER (IN/OUT)
• Incoming Plant Power (230v, 1PH, 50/60hz)
o If local disconnect is used (typically on the door of the CD30):
 1
st
hot leg into terminal 35 (L)
 2
nd
hot leg into terminal 36 (N)
 Ground into terminal 38 (PE)
o If not local disconnect is present (i.e. chassis mounted)
 1
st
hot leg into terminal 31 (L)
 2
nd
hot leg into terminal 32 (N)
 Ground into terminal 38 (PE)
• Outgoing power to coil (removable connector on bottom of CD30)
o 1
st
hot leg into terminal 41 (A1)
o 2
nd
hot leg into terminal 42 (A2)
o Ground into terminal 43 (PE)
