2/14
INDEX
SAFE USAGE OF THE PROJECTOR 3
INSTALLING THE PROJECTOR 4
CONTROL CONNECTION 4
DMX TERMINATOR 5
SETUP OPTIONS-PROJECTOR CONFIGURATION 6
TO SET THE DMX START ADDRESS 6
TIMING SETUP FOR THE PROJECTOR 7
OPERATION MENU 7
DMX PROTOCOL 8
INDICATION OF LED DIGITAL TUBE 9
MAINTENANCE 9
TROUBLESHOOTING 9
TECHNICAL DATA 10
ELECTRICAL DIAGRAM 12
COMPONENT ORDER CODES 13
Please note that as part of our ongoing commitment to continuous product development, specifications are subject to change without
notice. Whilst every care is taken in the preparation of this manual we reserve the right to change specifications in the course of
product improvement. The publishers cannot be held responsible for the accuracy of the information herein, or any consequence
arising from them.
Every unit is tested completely and packed properly by the manufacturer. Please make sure the packing and / or the unit are in good
condition before installation and use. Should there be any damage caused by transportation, consult your dealer and do not use the
unit. Any damage caused by improper use will not be assumed by the manufacturer and / or dealer.
ACCESSORIES
These items are packed together with the projector:
Name Quantity Unit Remark
Barn door
1
Set
Clamp
1
Pc
Safety cord
1
Pc
XLR cable
1
Pc With 5-pin plug
Power cord
1
Pc
This manual
1
Pc
