PR 9106B - Page 14

12 9106 - Product Version 9106-001
Visualisation in 4501 of hardware / software error
Readout at hardware error
Error search Readout Cause
Communications test 4501 / 9106 NO.CO Connection error
EEprom error - check configuration FL.ER
Configuration error or crc
mismatch, recovery
configuration is loaded
User error
II
! /
II
!
Loop limit exceeded
User error
II
! /
II
!
Loop error
EEprom error - check configuration
EE.ER /
IE.ER
Invalid configuration
(CRC or data)
Hardware error SU.ER Supply error
Hardware error RA.ER RAM error
Hardware error
FL.ERI
Flash error
Hardware error IN.ER Initialisation error
Hardware error C1.ER Hardware error - channel 1
Hardware error C2.ER Hardware error - channel 2
Hardware error DE.ER General error
! All error indications in the display flash once per second. The help text explains the error. In case
of cable fault the backlight also flashes. This can be reset by pressing the 3 key.
Errors affecting both channels are shown as error on channel 1 - and the line showing channel 2 is
blank.
Hardware error can be reset in two ways. Either step through the menus (if the other channel is to
stay in operation) or power cycle the device.
