Pramac P2000i - Spark Plug Maintenance

INVERTER GENERATOR – P2000i
32
5.2 Spark Plug Maintenance
Spark plug inspection
The spark plug is an important engine component and should be checked
periodically.
1. Remove the screws 1 and then remove the cover 2.
2. Remove the spark plug cap 3 and access cap 4.
3. Insert the tool 5 through the hole in the outside of the cover.
4. Insert the handlebar 6 into the tool 5 and turn it counterclockwise to
remove the spark plug.
5. Check for discoloration. The carbon porcelain insulator around the
center electrode of spark plug should be a Medium-to-light tan color.
6. Check the spark plug type and gap. The spark plug gap should be
measured with a w ire thickness gauge and, if necessary, adjusted to
specification.
Spark Plug Type:
BPR6HS (NGK)
Spark Plug Gap:
0.6-0.7 mm (0.024-0.028 in)
Spark Plug Torque:
20.0 N-m (2.0kgf m,14.8 Ibf
ft)
7. Install spark plug, spark plug cap, cover and screws.
