Pramac S5000 - S5000 GENERATOR PARTS

S5000 GENERATOR PARTS
21
S5000 GENERATOR PART LISTS
ITEM
Q.TY
PART NO.
DESCRIPTION
1 1 VA40011023- Frame Assembly
2* 1 ////////// Ground Wire Assembly
3* 1 ////////// Control Panel Assembly
4 1 AMM4900RB0000Y Alternator
5 1 EHB90BB20Z Honda GX270 Engine
6* 1 ////////// Engine Sub-Frame Assembly
7* 1 ////////// Fuel System Assembly
8 6 G020802 Flange Bolt, M6x10
9 5 G034308 Nut M8 - Nylon Insert
10 1 G041413 Flat Washer M8
11 2 SA40023901 Spacer 7mm
12 1 G052182 Vibration Isolation
13 1 VA9405- Shield Control Panel
14 1 VA8429- Heat Shield
15 1 G70188 Grommet
16 1 VA9403- Governor System Shield
17 3 G041204 Flat Washer
18 3 G022013 Bolt M8x30
NOTE: For Items with (*) see the sub-assembly details for actual part number
