S10000 GENERATOR PARTS
29
ITEM QTY. PART NO. DESCRIPTION
1 1 EHB180CBE9Z Honda GX610
2 1 AMM10500RB0000Z Alternator S20FS-130/A
3 1 VA8429-9005 Heat Shield
4* 1 Fuel Assembly Fuel System Assembly
5 1 VA40011038-PRAMAC Frame Assembled
6 1 G051121 Plug, 1"
7 1 VA40011012-9005 Control Panel Box
8 1 SA40011901 Deluxe Panel, 10kW, 18HP
9 1 VA9405-PRAMAC Shield Control Panel
10 1 G92695 Battery Cable, Negative
11 1 G92694 Battery Cable, Positive
12 1 VA40011704-9005 Hold Down Bar, Battery
13* 1 G089101 12V 17Ah Battery
14 1 G052182 Vibration Isolator
15 1 G052181 Vibration Isolator
16
1
VA40002703-9005 Sub-Frame, Engine
17
1
G92729 Wire, Ground
*NOTES: See page 22 for Item 4*. Item 13*, Battery, not included –shown for clarity.
