EASYKA – EASYBKA
________________________________________________________________________________________________________________________________________________________________________________________________
13
3.3 Wiring the Auxiliary Input and Output
4. NORMAL, SECURE & MASTER USERS
The EASYKA accepts up to 500 users and provides entry via the use of PIN codes. Each user is provided
with two code memory slots, Memory Slot 1 (Primary Code) and Memory Slot 2 (Secondary Code). The way
in which the two memory slots are programmed determines a users access level and also determines the
way in which the EASYKA grants access in its three Modes of Operation.
There are three user levels:
Normal User
A Normal User only has a Primary Code and is only granted access when the EASYKA is in Normal or
Bypass Mode.
Secure User
A Secure User must have a Primary and Secondary Code programmed, the two codes must not be the
same. The Secure User can gain access when the EASYKA is in any of its three Modes of Operation. In
Normal Mode the Secure User must use their Primary Code to gain entry. In Secure Mode the Secure User
must present both their Primary and Secondary Codes in order to gain entry.
Master User
A Master User must have both Primary and Secondary Codes programmed with the same PIN code. The
Master User can gain access during any Mode of Operation by presenting their PIN code to the controller.
(The Master User is convenient but is less secure than a Secure User).
5. MODES OF OPERATION
The EASYKA has 3 Modes of Operation :
1. Normal Mode
Normal Mode is the default mode and the Mode LED is green. In Normal Mode the
door is locked until a Primary Code is presented to the controller. Special codes
such as "Open Code" and "Auxiliary Code" are active in Normal mode. (see par. 9 and 10).
POWER
SUPPLY
12V-24V AC/DC
Relay
N.C.
COM
N.C.
Optional Varistor
To Next Page
