Precise Instrument DAT 400 - Fieldbus Protocol Data Areas; Output Data Area Description

Page 50
OUTPUT DATA AREA
Dirección
Descripción Formato NoteByte Bit
128 0 Command_Register INT See table D Page 45
130 0 Logic_Output INT
132 0 SP_1 DINT
136 0 SP_2 DINT
140 0 Data_Register DINT
144 0 Load_Cell_Capacity DINT
148 0 Load_Cell_Sensitivity INT
150 0 Weight_Division_Value INT See table E Page 45
152 0 Tare_of_the_System DINT
156 0 Capacity_of_the_System DINT
160 0 Filter_Value INT
162 0 Weight_Stability_value INT
164 0 Autozero_Set DINT
168 0 Tracking_Factor INT
170 0 Zero_Band INT
172 0 Not used BYTE
173 0 Set_1_Net_Weight BOOL See table F Page 46
173 1 Set_1_Gross_Weight BOOL See table F Page 46
173 2 Set_1_NO_NC BOOL See table F Page 46
173 3 Set_1_Pos_Neg_Values BOOL See table F Page 46
173 4 Set_1_Control BOOL See table F Page 46
174 0 Set_1_Hysteresys DINT
178 0 Set_1_Timer INT
180 0 Set_1_Delay INT
182 0 Not used BYTE
183 0 Set_2_Net_Weight BOOL See table F Page 46
183 1 Set_2_Gross_Weight BOOL See table F Page 46
183 2 Set_2_NO_NC BOOL See table F Page 46
183 3 Set_2_Pos_Neg_Values BOOL See table F Page 46
183 4 Set_2_Control BOOL See table F Page 46
184 0 Set_2_Hysteresys DINT
188 0 Set_2_Timer INT
190 0 Set_2_Delay INT
192 0 Monitor_Register INT
WRITING EXAMPLES
To write the set-up parameters following the example:
In the byte 128 (Command Register) write value Hex 7FFF. This value opens the writing area of the
DAT 400.
