HEADSTOCK
Ref. Mfr. No. Description Qty. Ref. Mfr. No. Description Qty.
1 2034 Spindle: D1-4 camlock, MT5 1 62 Key: 5 x 20 1
2 2035 Lock pin 3 63 2063 Plug 1
3 Spring: 0.6 × 4 × 22 3 64 Circlip 1
4 Screw: M8 x 16 skt hd 3 65 Ball bearing: 20 x 42 x 12 1
5 2038 End cap 1 66 2010B Shaft (input) 1
6 2006 Oil seal 1 67 Key: 5 x 80 1
7 D7212 Taper roller bearing 60 x 110 1 68 Key: 5 x 24 1
8 2031 Gear: 83T 1 69 2019 Gear: 47T 1
9 2030 Gear: 46T 1 70 2018 Gear: 23T 1
10 2029 Gear: 59T 1 71 2013 Gear: 42T 1
11 2024 Nut 1 72 47 Circlip 1
12 2008 Gear: 45T 1 73 Ball bearing: 25 x 47 x 12 2
13 D7211 Taper roller bearing 55 x 110 1 74 Circlip 1
14 2007 Nut, special 2 75 2012B Flange 1
15 2005A End cap 1 76 Oil seal: 25 x 40 x 10 1
16 2023 Oil seal 1 77 Screw: M6 x 20 skt hd 4
17 Screw: M8 x 16 skt hd 4 78 2014 Pulley 1
18 Screw: M8 x 8 set 2 79 2011 Washer 1
19 2025 Pin 2 80 Screw: M8 x 20 skt hd 1
20 Screw: M8 x 16 skt hd 4 81 Oil seal 1
21 Screw: M3 x 8 skt hd 2 82 Screw: M6 x 8 set 1
22 Key: 8 x 45 1 83 2001 Shaft, idler ** 1
23 Key: 8 x 80 1 84 Circlip 2
24 2037 Locking cam 3 85 2032 Gear: pair 40/45T 1
25 Screw: M8 x 16 skt hd 5 86 Ball bearing: 20 x 47 x 14 1
26 2040 End cap 1 87 Circlip 1
27 2028 Oil seal 1 88 Screw: M6 x 30 skt hd 6
28 Ball bearing: 20 x 52 x 15 1 89 Screw: M6 x 20 set 2
29 2039 Top shaft 1 90 Plug, oil drain, M16/1.5 1
30 2017 Gear: 21T 1 91 Oil seal: 16 x 2.4 1
31 Key: 5 x 18 2 92 Plug, oil fill, M16/1.5 1
32 2015 Gear: 58T 1 93 2044 Headstock cover 1
33 2016 Gear: 45T 1 94 2062 Oil seal 1
34 Circlip 1 95 2033 Headstock casting 1
35 2022 Gear: 31T 1 96 Pin: 4 x 24 2
36 2020 Gear: 55T 1 97 Oil seal: 16 x 2.4 7
37 2021 Gear: 36T 1 98 2046 Shaft, gear shifter 2
38 Circlip 1 99 2042 Crank 2
39 Ball bearing: 20 x 42 x 12 1 100 Pin: 4 x 24 3
40 2009 End cap 1 101 Circlip 3
41 2009A Oil seal 1 102 2041 Shoe, gear shift 2
42 Key: 8 x 108 1 103 Key: 5 x 16 2
43 Screw: M3 x 8 skt hd 2 104 2058 Shift lever 3
44 Oil seal 1 105 2059 Hub 2
45 2055 Faceplate 1 106
Steel ball: Ø5
4
46 Screw: M3 x 8 skt hd 6 107 Spring: 1 x 6 x 20 4
47 Screw: M6 x 12 skt hd 2 108 2047 Gear, meshes with 114 2
48 2003 Washer 2 109 Screw: M8 x 8 set 4
NOTE
Dimensions are in mil-
limeters.
All gears: pressure
angle 20 degrees,
module M2 (except
item 59).
Bearings: reference
numbers in this list
may not be recognized
by stockists.
If replacing a bearing
or oil seal, remove
and measure the item
in queson. Order re-
placement parts from
Quality Machines.
