APRON
Not shown Oil sight glass
Ref.
Mfr. No.
Description Qty. Ref. Mfr. Description
Qty.
1 4026 Bushing 1
28 4014 Gear: 25T
2 4029 Gear: 50T 1
29 4016 Hub
3 Pin: 5 x 30 1
30 4001 Apron case
4 4027 Spacer 1
31 Screw: set M6 x 6 1
5 4028 Gear shaft: 11T 1
32 4010 Gear: 25T 1
6
4008
Worm bracket 1
33 4011 Shaft 1
7
4009 Worm 1 34 Screw: skt hd M6 x 45 3
8 Key: 5 x 36
1 35 Screw: set M8 x 8 1
9
4032 Handle 1
36 Spring: 1 x 45 x 6 2
10
4033 Shoulder bolt 1 37 Ball 2
11
4034 Handwheel 1 38 4041 Lever 1
12 4036 Graduated collar
1
39 4042 Splined shaft
1
13 Screw: skt hd M6 x 20
2
40
Pin: 5 x 25 1
14 4031 Hub 41
4020 Bushing 1
15 Oiler 42
4019
Gear: 14T
1
16 4030 Gear shaft: 15T
43
Pin: 5 x 25 1
17 Screw: skt hd M6 x 12 1
44
4018 Shaft 1
18
4035 Washer 1
45
4017 Worm gear, 24T 1
19
Screw: skt hd M6 x 10 4
47
Screw: set M5 x 33 2
20
4038 Washer 1
49
Screw: skt hd M6 x 10 1
21
4039 Post 1
50
Screw: set M6 x 6 1
22
Key: 5 x 16 1
51
4043 Limit stop 1
23
4037 Leaf spring 1
52
4025 Lock collar 1
24 4015 Shaft, power feed select
53
4024 Shaft 1
25 4012 Gear: 48T 54 Screw: set M8 x 8 1
26 Pin: 5 x 33 1 55 4045 Boss, split-nut shaft 1
27 4013 Gear: 51T 56 Pin: 5 x 40 1
Worm rides on feed
sha, not shown,
drives gear #45
#52, #57 and related components
prevent accidental closing of the half
nuts #70 when cross slide feed or
carriage feed is engaged by lever #39
Splines on #39 engage
with grooves on #24
