Precision matthews PM-1440BV

31PM-1440BV v3 2020-10 Copyright © 2020 Quality Machine Tools, LLC
STAND COMPONENTS Fig 1
Dimensions in millimeters
Ref Description Part
1 Socket head screw M6×12 Z3028
2 Special washer 6 Z3029
3 Splash guard Z3030
4 Screw M5×8 Z3031
5 Screw M4×28 Z3032
6 Pin 3×16 Z3033
7 Connecting rod Z3034
8 Spring pin 5×25 Z3035
9 Backstop Z3036
10 Rocker Z3037
11 Shaft Z3038
12 Pin Z3039
14 Pulley Z3040
15 Washer 8 Z3041
16 Socket head screw M8×16 Z3042
16a Key 8×20 Z3073
19 Main tray Z3043
20 Slide-out chip tray Z3044
21 Coolant pump Z3045
22 Hose connector Z3046
23 Coolant container Z3047
24 Socket head screw M10×30 Z3048
25 Hexagon nut M10 Z3049
Ref Description Part
26 Socket head screw M6×10 Z3050
27 LH stand casting Z3051
28 Rear cover Z3052
29 Screw M5×12 Z3053
30 End cover Z3054
31 Extension spring Z3055
32 Pin Z3056
33 Bushing Z3057
34 Socket head screw M6×40 Z3058
35 Spring pin 5×40 Z3059
36 Rocker Z3060
37 Foot brake shaft Z3061
38 Panel support angle Z3062
39 Hexagon nut M6 Z3063
40 Special washer 6 Z3064
41 Socket head screw M6×12 Z3065
42 Roll pin 5×28 Z3066
43 Panel Z3067
44 Brake pedal Z3068
45 Shaft Z3069
46 RH stand casting Z3070
47 Lift hole cover Z3071
48 Coolant return chute Z3072
