HEADSTOCK DRIVE COMPONENTS Fig 5
Ref Description Part
3 Retaining ring: 62, int Z5876
4 Bearing housing Z5877
5 Retaining ring: 35, ext Z5878
6 Ball bearing: 6007 (2) Z5879
7 Gear: 57T Z5880
8 Splined spindle sleeve, 29T gear Z5881
9 Key Z5882
10 Oil seal: 20 x 42 x 7 (2) Z5883
11 Oil seal housing Z5884
12 Screw: M5 x 16, ph hd (3) Z5885
13 Gasket Z5886
28 Quill Z5887
29 Quill base Z5888
33 Washer: lock 6 Z5889
34 Nut: M6 hex Z5890
35 Screw: M6 x 35, skt hd Z5891
36 Taper roller bearing: 30205 Z5892
37 Washer: 25, tabbed Z5893
38 Nut: M25, spanner type Z5894
48 End cap Z5895
49 Spindle Z5896
50 Taper roller bearing: 30207 Z5897
75 Screw: M5 x 10, set (4) Z5898
76 Ball bearing: 6001 (5) Z5899
77 Spacer bush Z5900
78 Gear, 27T Z5901
79 Gear, 21T Z5902
80 Gear, 36T Z5903
81 Shaft, H-L group Z5904
82 Key, 5 x 70 Z5905
83 Key, 5 x 36 Z5906
84 Screw: M5 x 10, set (2) Z5907
Ref Description Part
85 Ball, 6.5 Z5908
86 Compression spring Z5909
87 Gear, 46T Z5910
88 Key, 5 x 16 Z5911
89 Gear, 18T Z5912
90 Retaining ring: 28, int Z5913
91 Top casting plug (2) Z5914
92 O-ring, 23.6 x 3.55 Z5915
93 Motor: 120V, single phase, 900 W Z5916
94 Key, 6 x 36 Z5917
95 Screw: M8 x 12, skt hd (4) Z5918
96 Motor plate Z5919
97 Screw: M6 x 16, skt hd (4) Z5920
98 Screw: M6 x 40, skt hd (6) Z5921
99 Taper pin, 8 x 35 (2) Z5922
100 Oil ller plug Z5923
101 Headstock top casting Z5924
102 Motor shaft Z5925
103 Ball bearing: 6006 Z5926
104 Retaining ring: 55, int Z5927
105 Oil seal: 30 x 55 x 10 Z5928
106 Retaining ring: 16, ext Z5929
107 Gear, 23T Z5930
108 Key, 6 x 25 Z5931
109 Gear, 38T Z5932
110 Gear, 32T Z5933
111 Shaft, 2-3-1 group Z5934
112 Key, 5 x 60 Z5935
113 Key, 5 x 10 Z5936
114 Gear, 41T Z5937
115 Spacer bush Z5938
To Next Page
