Precision Power ATOM A400.4D - Page 7

5
ADDITIONAL SPECIFICATIONS
A1200.1D
• 400w x 1 @ 4-ohm Mono
• 700w x 1 @ 2-ohm Mono
• 1,200w x 1 @ 1-ohm Mono
• Variable 50-500Hz 12dB Low Pass Filter
• Variable 20-50Hz 12dB Subsonic Filter
• Selectable 0-180。Phase Switch
• Variable 0-18dB 45Hz Bass Boost
• Total Harmonic Distortion: 0.3% @ 4-ohm
• Frequency Response: 20 - 500Hz
• Signal-to-Noise Ratio: 90dB
• Input Sensitivity: 250mV-6V
• Dimensions: 6"W x 2.25"H x 10"L
6
REMOTE INPUT HI-IN P U T
+ L - G - R +
L
GND
10 11
7 1
20A
20A
20A
20A
MASTER
SLAVE
