ADDITIONAL SPECIFICATIONS
A1000.5D
FUSES POWER INPUT
SPEAKERS OUT
REMOTE
HI-INPUT SUB REAR FRONT HI-INPUT
+ L - G - R +
+ L - G - R + + L - G - R +
SUB
AUTO TURN ON
REAR
AUTO TURN ON
FRONT
AUTO TURN ON
A1000.5D DC12V REM GND SUB WOOFER
BRIDGED MODE
REAR
BRIDGED MODE
FRONT
GAIN CONTROL
R R
8 9 10 11 8 7 7 6 2 1 2
GAIN X-OVER GAIN X-OVER SUM GAIN SUB SONIC PHASE SHIFT BASS BOOST LOW PASS
A1000.5D
6.0V ~ 0.25V
LPF HPF
FULL
50Hz ~ 500H z 6.0V ~ 0.25V
LPF HPF
FULL
50Hz ~ 500Hz
OFF ON
6.0V ~ 0.25V 20Hz ~ 50Hz
0° 180°
0dB ~ 18dB 50Hz ~ 500H z
at 45Hz
FRONT REAR SUB
5 CHANNELS CLASS D PREMIUM AUDIO SYSTEM
18 18
13 19 15 13 19 15 20 13 14 3 17 16
• 60W x 4 (4-ohm Stereo) + 250W x 1 (4-ohm Mono)
• 100W x 4 (2-ohm Stereo) +450W x 1 (2-ohm Mono)
• 200W x 2 (4-ohm Bridged) + 450W x 1 (2-ohm Mono)
• Variable 50-500Hz 12dB High Pass Filter (chs. 1-4)
• Variable 50-500Hz 12dB Low Pass Filter (chs. 1-5)
• Variable 20-50Hz 12dB Subsonic Filter (ch. 5)
• Selectable 0-180。Phase Switch (ch. 5)
• Variable 0-18dB 45Hz Bass Boost (ch. 5)
• Total Harmonic Distortion: 0.05% @ 4-ohm
• Frequency Response: 20- +20KHz
• Signal-to-Noise Ratio: 90dB
• Channel Separation: ≤55dB
• Input Sensitivity: 250mV-6V
• Dimensions: 6"W x 2.25"H x 13.25"L
5
20A
20A
20A
L
L
