Precision Power ATOM A400.4D - Page 5

GAIN X-OVER GAIN X-OVER
FRONT
REA R
13 19 15 13 19 15
ADDITIONAL SPECIFICATIONS
A700.4D
• 100W x 4 @ 4-ohm Stereo
• 175W x 4 @ 2-ohm Stereo
• 350W x 2 @ 4-ohm Bridged
• Variable 50-500Hz 12dB High Pass Filter
• Variable 50-500Hz 12dB Low Pass Filter
• Variable 0-18dB 45Hz Bass Boost
• Total Harmonic Distortion: 0.05% @ 4-ohm
• Frequency Response: 20- +20KHz
• Signal-to-Noise Ratio: 90dB
• Channel Separation: ≤55dB
• Input Sensitivity: 250mV-6V
• Dimensions: 6"W x 2.25"H x 10"L
4
REAR
HI-IN PUT
+ L - G - R +
REAR
+ L - G - R +
FRONT
A700.4D
GND
REAR
FRONT
9 10
20A
20A
