TECHNICAL FEATURES
Atom amplifiers adopt the optimum class d performance, reliability, and footprint of the original
Atom and ion platforms. At first glance, you’ll notice several key improvements. ATOM’s signal inputs,
power/ground, and speaker connections are all relocated to the chassis's leading edge for an
easier, more appealing install. All pre-amp & crossover options are conveniently located on the
backside. You might not notice additions to the circuit board, including increased power supply &
output stage components & monoblock bridging capability. Installation of Atom amplifiers is unique,
using a mounting pedestal at each corner. The pedestals elevate the heatsink, improving airflow
around and under the chassis. Additionally, rubber grommets under and inside each pedestal
electrically isolate the amplifier chassis from the vehicle chassis, reducing the potential for ground
loop noise.
ADDITIONAL SPECIFICATIONS
A400.4D
HI/LOW INPUT
FRONT
GAIN
X-OVER
DC12V REM GND
+ L - G - R +
12.0V ~ 0.5mV
HPF
FULL
LPF
50Hz ~ 500Hz
L R L R
- +
HI/LOW INPUT X -OVER
BRIDGED
L R L R
12.0V ~ 0.5mV
GAIN
-
50Hz ~ 500Hz
REAR
+
FRONT
+ L - G - R +
HPF FULL LPF
REAR
SPEAKERS OUT
POWER INPUT
18
2 13 19 15 7 9 10 11
• 60W x 4 @ 4-ohm Stereo
• 100W x 4 @ 2-ohm Stereo
• 200W x 2 @ 4-ohm Bridged
• Variable 50-500Hz 12dB High Pass Filter
• Variable 50-500Hz 12dB Low Pass Filter
• Total Harmonic Distortion: 0.05% @ 4-ohm
• Frequency Response: 20- +20KHz
• Signal-to-Noise Ratio: 90dB
• Channel Separation: ≤55dB
• Input Sensitivity: 250mV-6V
• Dimensions: 6"w x 2.25"H x 6"L
