4
QBASS
PLUS
™
Q
BASS PLUS
™
On the
PC1800
amplifier, we've taken bass control
to a higher level with
Q
BASS PLUS
™
. The two
Q
BASS
switches (labeled 1 and 2) on the front end of the
amplifier allow you to select one of four frequency centers
30Hz, 36Hz, 44 Hz and 60 Hz. The Q SELECT switch
determines the width of boosted frequencies. A 'Q' of 2
(switch out) will give you a wide boost while a 'Q' of 4 will
boost a narrow range of frequencies. (See chart below.)
On the rear end panel you will find the
Q
BASS
™
level
control and the plug-in for an optional
Q
BASS REMOTE
™
dash mounted level control. Adjust the level control
clockwise for up to 18dB of boost at your selected
frequency and Q.
Q
BASS PLUS
™
QBASS™
Settings
1 2 Freq.
IN IN 30 Hz
IN OUT 36 Hz
OUT IN 44 Hz
OUT OUT 60 Hz
+18dB
+6dB
0dB
30Hz
36Hz
44Hz
60Hz
Q = 4
Q = 2
+12dB
CAUTION:
Q
BASS PLUS
™
should only be used in systems with
strong subwoofers. 18dB is a lot of bass boost and could damage full
range speakers.
Optional
Q
BASS REMOTE
™
This boost control can be mounted in the
dash and will supersede the boost
control on the endplate.
Optional
Q
PORT
™
expansion
module allows one boost control
to operate multiple amplifiers. Each
Q
PORT
™
has outputs for four amplifiers
as well as to another
Q
PORT
™
for greater
expansion. See your Authorized
PrecisionPower
Dealer
for more information!
QBASS
0
+18
Q
BASS REMOTE
™
Designed and handcrafted in the USA
™
