C944 Treadmill
Page 16
Diagram 4.2 - Limit Switch Bracket
Note:
The zero sense switch can be actuated if the center of the wheel is slightly above or slightly
below the widest point of the switch actuator. However, for best results, adjust the position of the
zero sense switch as described in the following step.
Lower Limit
Switch
Actuator
Zero Sense
Switch
Upper Limit
Switch
