Precor EFX 885 User Manual

EFX 885, 835, 825
Service Manual 20039-166
Page 106
©2011 Precor Incorporated, Unauthorized Reproduction and Distribution Prohibited by Law
8. Remove the two screws that fasten the back cover to the option cap and remove the cover. See Diagram 6.5.6
Diagram 6.5.6 Option Cap Back Cover
9. Remove the 6 screws that fasten the rear cover from the console and remove. See Diagram 6.5.7.
Diagram 6.5.7 Rear Console Cover

Precor EFX 885 Specifications

General

Resistance Levels	20
Drive System	Rear Drive
Power Requirements	Powered
Heart Rate Monitoring	Touch and telemetry
Console	Touchscreen
CrossRamp Technology	Adjustable
Weight Capacity	350 lbs
