Page 24 For technical questions, please call 1-888-866-5797. ITEM 62548
SAFETY SETUP OPERATION MAINTENANCE
Parts List and Diagram
Parts List
Part Description Qty.
1 Right Gearbox Cover 1
2 Transmission Shaft 1
3 Sprocket Shaft 1
4 Chain 1
5 Chain 1
6 Left Gearbox Cover 1
7 Oil Seal 25 x 38 x 7 2
8 Oil Seal Cover 2
9 Flange Nut M6 23
10 Hex Head Flange Bolt M6 x 12 21
11 Elastic Ring Ø15 3
12 Deep Groove Ball Bearing 6202-2Z 2
13 Flat Washer Ø6 4
14 Hex Head Bolt M6 x 20 1
15 Spring Washer Ø6 1
16 Wear-Resistant Washer 15.2 x 18.9 x 0.5 1
17 Flat Gasket 12 x 24 x 1 4
18 Paper Gasket 13 x 30 x 1 2
19 Drive Gear Assembly 1
20 Gearbox Shaft 1
21 Left Engine Mounting Bracket 1
22 Right Engine Mounting Bracket 1
23 Support Pin 1
24 Connecting Rod 1
25 Sleeve 8 x 11 x 26 4
26 Wheel Bracket 1
27 Wheel 2
28 Hex Head Bolt M8 x 25 1
29 Flange Nut M8 9
30 Spacer 12 x 16 x 37 2
31 Hex Head Bolt M12 x 65 2
32 Flat Washer Ø12 4
33 Lock Nut M12 2
34 Drag Bar Holder 1
35 R-Clip 6
36 Forward Gear Tension Pulley Assembly 1
37 Hex Head Bolt M8 x 30 3
38 Forward Drive Pulley 1
39 Reverse Gear Drive Pulley 1
40 Engine 1
41 Cable Plate 1
42 Drive Wheel 1
43 Cable Bracket 2
44 Reverse Gear Tension Pulley Spring 1
45 Forward Clutch Belt 13 x 1050LW 1
46 Belt Cover 1
47 Handlebar Cover 1
48 Handle Grip Ø25 2
Part Description Qty.
49 Handle Frame 1
50 Connecting Plate 1
51 Left Handlebar 1
52 Right Handlebar 1
53 Spacer 20 x 25 x 9 2
54 Left Tine Shield 1
55 Right Tine Shield 1
56 Tine Shaft 2
57 Left Tine Blade 8
58 Right Tine Blade 8
59 Hex Head Bolt M10 x 30 16
60 Spring Washer Ø10 16
61 Nut M10 16
62 Nut M8 11
63 Hex Head Bolt M8 x 16 1
64 Clevis Pin 8 x 43 4
65 Hex Head Flange Bolt M8 x 65 2
66 Flat Washer 8 8
67 Spring Washer 8 11
68 Hex Head Flange Bolt M8 x 70 2
69 Hex Head Flange Bolt M8 x 40 8
70 Hex Head Bolt 5/16-24 M8 x 2 1
71 Hex Head Flange Bolt M8 x 20 4
72 Hex Head Flange Bolt M8 x 50 4
73 Hex Head Flange Bolt M8 x 16 2
74 Cross Groove Head Bolt M5 x 12 2
75 Nut M8 1
76 Hex Head Bolt M8 x 20 2
77 Clevis Pin 6 x 35 1
78 Clevis Pin 10 x 45 1
79 Lock Nut M10 2
80 Hex Head Bolt M10 x 35 1
81 Elastic Ring Ø8 1
82 Hex Head Flange Bolt M8 x 25 4
83 Engine On/Off Switch Assembly 1
84 Throttle Control 1
85 Reverse Gear Tension Pulley Assembly 1
86 Reverse Clutch Belt 9 x 1133LW 1
87 Left Drag Bar Support 1
88 Right Drag Bar Support 1
89 Forward Clutch Lever 1
90 Reverse Clutch Lever 1
91 Drag Bar 1
92 Forward Clutch Cable 1
93 Reverse Clutch Cable 1
94 Throttle Cable 1
95 Lock Nut M8 7
96 Large Washer Ø8 1
To Next Page
