Page 6 For technical questions, please call 1-888-866-5797. ITEM 63080
SAFETY SETUP OPERATION MAINTENANCE
Functional Description
Specifications
Generator
Output
120 / 240 VAC, 60 Hz
3,200 Running Watts (4,000 Peak Watts)
Electrical Receptacle
Two 3-Prong, duplex NEMA #5-20 120 V GFCI
One 4-Prong, NEMA #L14-30 twistlock 120 V / 240 V
One DC Outlet 12 VDC
Engine
Displacement 212 cc
Engine Type Horizontal Single Cylinder 4 stroke OHV
Cooling System Forced air cooled
Fuel
Type 87+ octane stabilizer treated unleaded gasoline
Capacity 4 Gallons
Engine Oil
Type SAE
10W – 30 above 32° F
5W – 30 at 32° F or below
Capacity 0.6 Quart
Spark Plug
Type NHSP
®
/ Torch
®
F6TC
Gap 0.027" – 0.031"
Valve Clearance
Intake 0.004" – 0.006"
Exhaust 0.006" – 0.008"
Run Time
@ 50% load 10 hr.
Operational Volume
@ 3 feet 70 dB
Available accessories Wheel kit (sold separately)
The emission control system for this Generator’s Engine is warranted for standards set by the U.S. Environmental
Protection Agency. For warranty information, refer to the last pages of this manual.
Components and Controls
DC Circuit Breaker
AC Circuit Breakers
DC Receptacle
GFCI AC Receptacles
Fuel Cap
Frame
Starter
Handle
Fuel Valve
Power Switch
Choke
Low Oil Indicator
AC Receptacle
Air Filter
Ground Terminal
