Page 19
For technical questions, please call 1-888-866-5797.
ITEM 70143
SAFETYOPERATIONMAINTENANCE SETUP
Nominal 12 VDC Output
1. Move the Economy (ESC) Switch to
the OFF position.
2. Only use the 12 VDC receptacle
and provided charging cable with
clamps to charge a 12 volt lead-acid
type battery. Do not overcharge.
3. Do not connect any device
to the 12 VDC terminal that
draws more than 8 amps.
4. If this 12 VDC circuit protection is
tripped, reduce the load, and press
the Reset Button next to the outlet.
DC 12 V 8 A
RESET
ESC THROTTLE
ON
OFF
