Predator 70143 - Parts List and Diagram; Generator Parts List

Page 30
For technical questions, please call 1-888-866-5797.
ITEM 70143
SAFETY OPERATION MAINTENANCESETUP
Part Description Qty
1 Engine Assembly 1
2 Screw M4 x 8 4
3 Decorative Board 1
4 Sealing Ring 1
5 Left Housing 1
6 Maintenance Access Panel 1
7 Right Housing 1
8 Battery and Oil Fill Access Panel 1
9 Cover 1
10 Side Cover Knob 4
11 Panel Rear Cover 1
12 Muffler Baffle 1
13 Engine Bottom Plate 1
14 Hub Cap 4
15 Wheel 4
16 Brake Assembly 1
17 Carbon Canister/Fuel Tank Connecting Pipe 1
18 Carbon Canister/Air Filter Connecting Pipe 1
19 Exhaust Sealant 1
20 Handle Decoration Block 1
21 Oil Switch Bracket 1
22 Rod Components 1
23 Inverter Bracket 2
24 Inverter 1
25 Handle 2
26 Left Front Pillar 1
27 Right Front Pillar 1
28 Left Rear Pillar 1
29 Right Rear Pillar 1
30 Tank Front Bracket 1
31 Tank Back Bracket 1
32 Tank Right Support 1
33 Battery Holder 1
34 Axle 4
35 Panel Comp 1
36 Wiring Harness 1
37 Intake Connector 1
38 Switch Axis 1
39 Tee 1
40 Front Shroud 1
41 Microswitch 1
42 Plug 1
43 Sealing Ring 2
44 Outlet Connector 1
45 Self-Tapping Screw M4 x 16 2
46 Knob Plug 1
47 Carbon Canister Assembly 1
48 Circlip Ø6 4
49 Grounding Wire 2
50 Starter Grip 1
51 Starter Grip Cover 1
52 Fuel Filter 1
53 Connector 1
54 Fuel Cock 1
55 Gear 1
Part Description Qty
56 Gear 1
57 Upper Cover 1
58 Lower Lid 1
59 Fuel Tank Cap 1
60 Fuel Filter 1
61 Clip 6
62 Oil Switch Bracket 1
63 Rubber Gasket 8
64 Jacket 1
65 CO Module 1
66 Back Shroud 1
67 Cable Tray 1
68 DC Voltage Regulator 1
69 Control Module 1
70 Bolt M6 x 20 4
71 Bolt M6 x 25 2
72 Pan Head Tapping Screw ST4.2 x 13 8
73 Fuel Line Clip Ø9.5 x 0.8 2
74 Rotor Bolt Gasket 4
75 Fuel Hose Clip Ø10 3
76 Screw M5 x 12 14
77 Bolt M6 x 12 38
78 Nut M8 4
79 Locking Clip 32
80 Screw M4 x 16 1
81 Tooth Washer 5
82 Inner Hexalobular Tooth Tamper Proof Bolt 2
83 Flat Gasket Ø4 1
84 Wire Sleeve 1
85 Adhesive Strip 1
86 Left Handle Bracket 2
87 Right Handle Bracket 2
88 Pull Rod Pressing Plate 2
89 CO Bracket 1
90 Bolt M6 x 25 6
91 Bolt M6 x 16 50
92 Fuel Pipe 1
93 Fuel Pipe 1
94 Foot Pad 2
95 Battery 1
96 Battery Wiring Assembly 1
97 Knob 1
98 Cable 1
99 Butterfly Bolt M6 x 12 2
100 Fuel Tank 1
101 Spring 1
102 Steel Ball 1
103 Conical Countersunk Head Screw 4.2 x 13 1
104 Fuel Gauge 1
105 Rubber Sleeve 1
106 Filter 1
107 Fuel Hose Clip Ø8.5 4
108 Flat Gasket Ø10 x Ø20 x 2 4
109 Flat Gasket Ø8 4
110 Fuel Tank Lower Beam Bracket 1
Parts List and Diagram
Generator Parts List
