Engine Parts List
Part Description Qty
1A Crankcase 1
2A Ball Bearing 2
3A Oil Seal 1
4A Bolt M6 x 16 11
5A Drain Plug Bolt 1
6A Drain Plug Washer 2
7A Crankcase Cover Dowel Pin 4
8A Piston 1
9A Piston Ring Set 1
10A Connecting Rod Assembly 1
11A Piston Pin 1
12A Piston Clip 2
13A Crankcase Cover Assembly 1
14A Dipstick 1
15A Intake Valve 1
16A Exhaust Valve 1
17A Intake Valve Returner 1
18A Valve Spring 2
19A Valve Spring Seat 2
20A Valve Lock Clamp 4
21A Rotator 2
22A Stud Bolt 2
23A Nut M6 2
24A Crankshaft Assembly 1
25A Valve Lifter 2
26A Crankcase Cover Gasket 1
27A Camshaft Assembly 1
28A Dowel Pin 2
29A Bolt M8 x 30 6
30A Cylinder Head Gasket 1
31A Bolt M8 x 60 4
32A Spark Plug 1
33A Push Rod 2
34A Bolt M6 x 12 5
35A Cylinder Head Cover Gasket 1
36A Cylinder Head Cover 1
37A Nut 1
38A Intake Gasket 1
39A Carburetor Gasket 1
40A Bolt M5 x 12 2
41A Temperature Sensor 1
42A Rocker Assembly 2
43A Adjuster Rocker Arm 2
44A Recoil Starter Assembly 1
45A Rotor 1
46A Bolt M6 x 60 3
47A Stator 1
48A Recoil Starter Fan 1
49A Starter Pulley 1
50A Ignition Coil 1
51A Wind Deflector Shroud 1
52A Bracket 1
Part Description Qty
53A Bolt M6 x 35 1
54A Carburetor Insulator 1
55A Carburetor Assembly 1
56A Stepper Motor 1
57A Breather Tube 1
58A Stud Bolt 2
59A Fuel Line Clip Ø12 1
60A Recoil Starter Components 1
61A Carburetor Spacer 1
62A Oil Level Switch Assembly 1
63A Push Rod Guide Plate 1
64A Waterproof Cover 1
65A Bottom Plate Guide Hood 1
66A Cylinder Head 1
67A Bolt M6 x 25 4
68A Wind Deflector 1
69A Bolt M6 x 8 2
70A Air Cleaner Assembly 1
71A Fuel Line Clip 1
72A Inner Cylinder Head Cover 1
73A Bolt 1
74A Starter Motor Assembly 1
75A Fuel Line Clip Ø9.5 x 0.8 1
76A Fuel Line 1
77A Bolt M6 x 20 17
78A Stepper Motor 1
79A Bolt M4 x 20 1
80A Crossing Screw M4 x 6 4
81A Polyurethane Screen 3
82A Stepper Motor Bracket 1
83A Low Pressure Hose 1
84A Exhaust Sealant 1
85A Muffler Back Cover 1
86A Muffler Front Cover 1
87A Left Power Base Plate 1
88A Right Power Base Plate 1
89A Muffler Junction Plate 1
90A Vibration 4
91A Muffler 1
92A Bolt M8 x 45 4
93A Crossing Screw M4 x 25 2
94A Nut M8 2
95A Spring Washer Ø8 2
96A Nut M8 8
97A Drain Tube 1
98A Oil Plug 1
99A Bolt M6 x 28 1
100A Bolt M6 x 30 2
101A Wire Harness Clip 4
102A Low Pressure Hose Hoop 1
103A Wire Harness Clip 1
When ordering replacement parts from this list, the “A” suffix must be included in order to get the correct part.
