Predator 9000 - Parts List (continued)

Page 27For technical questions, please call 1-888-866-5797.ITEM 59134
SAFETYSETUPOPERATIONMAINTENANCE
Part Description Qty
115 Throttle Return Spring 1
116 Throttle Rod 1
117 Valve Adjustment Cap 2
118 Valve Locker 4
119 Valve Spring Retainer 2
120 Valve Inner Spring 2
121 Valve Oil Seal 1
122 Valve Spring Seat 1
123 Valve Kit 1
124 Flanged Hex Bolt 7
125 Oil Seal 2
126 Crankcase Cover 1
127 Oil Dipstick Assembly 2
128 Bearing 2
129 Bearing 1
130 Balancing Shaft 1
131 Crankcase Cover Gasket 1
132 Locating Pin 2
133 Governor Gear Assembly 1
134 Crankshaft 1
135 Oil Level Sensor 1
136 Connecting Rod 1
137 Steel Cable Baffle Ring 2
138 Piston 1
139 Piston Pin 1
140 Piston Ring Assembly 1
141 Camshaft Assembly 1
142 Valve Lifter 2
Part Description Qty
143 Push Rod 2
144 Crankcase Body 1
145 Oil Seal 1
146 Flat Washer 1
147 Speed Regulating Arm 1
148 Pin Clip 1
149 Speed Regulating Bracket 1
150 Starter Motor Assembly 1
151 Starting Relay 1
152 Manual Starting Assembly 1
153 Flanged Hex Bolt 2
154 Cable Cleat 1
155 Engine Oil Protector 1
156 Sealing Plug Screw 1
157 Flat Washer 2
158 Locating Wire Nail 1
159 Wire Bundle Tension Disc 1
160 Charging Armature Assembly 1
161 Flanged Hex Bolt 2
162 Ignition Coil Assembly 1
163 Flanged Hex Bolt 2
164 Locating Wire Nail 2
165 Flywheel Assembly 1
166 Impeller 1
167 Starting Disc 1
168 Flanged nut 1
169 Canister Tube 1
Parts List (continued)
