Page 26 For technical questions, please call 1-888-866-5797. ITEM 59134
SAFETY SETUP OPERATION MAINTENANCE
Part Description Qty
1 Flanged Hex Bolt 16
2 Flat Washer 4
3 Power Socket Assembly 1
4 Weather Proof Cover 1
5 Panel Output Indicator Light 1
6 Start Control Switch 1
7 Weather Proof Cover 3
8 Panel Output - CO Indicator 1
9 Circuit Breaker 1
10 Circuit Breaker 1
11 Circuit Breaker 2
12 Flanged nut 14
13 Power Socket 1
14 Power Socket 2
15 Power Socket 1
16 Ground Terminal 1
17 Control Panel Components 1
18 Control Panel 1
19 Caulking 1
20 Flat Washer 6
21 Frame 1
22 Frame Gusset 1
23 Flanged Hex Bolt 6
24 Flanged nut 4
25 Rubber Engine Mount 4
26 Flanged nut 4
27 Flanged nut 8
28 Engine Ground Wire 1
29 Nut 2
30 Elastic Washer 1
31 Lock Washer 1
32 Rubber Foot 4
33 Flanged Hex Bolt 1
34 Motor Components 1
35 Carbon Brush 1
36 Motor Terminal Plate 1
37 Flat Washer 1
38 Rear Motor Support 1
39 Flanged Hex Bolt 4
40 Flanged Hex Bolt 2
41 Hex Bolt 1
42 Voltage Regulator 1
43 Flanged Hex Bolt 6
44 Rear Motor End Cover 1
45 Flanged Hex Bolt 7
46 Muffler Bracket 1
47 Muffler Guard Shield Rubber Pad 1
48 Muffler Guard Shield 1
49 Muffler 1
50 Muffler Exhaust Cover 1
51 Spark Arrestor 1
52 Muffler Vent Shield 1
53 Muffler Gasket 1
54 Flanged Hex Bolt 2
55 Tank Vibration Dampeners 4
56 Bushing 4
57 Flat Washer 4
Part Description Qty
58 Flanged Hex Bolt 4
59 Fuel Level Gauge 1
60 Phillips Countersunk Head Screw 2
61 Clamp 1
62 Tank Cover 1
63 Filter Screen 1
64 Tank 1
65 Fuel Valve Assembly 1
66 Engine 1
67 Motor Limit Stop 1
68 Motor Fan Housing 1
69 Flanged Hex Bolt 1
70 Air Filter Bracket 1
71 CO Sensor Module 1
72 Battery Clamp Bracket 1
73 Battery Clamp Bracket Bolts 2
74 Anode Lead 1
75 Clamp 2
76 Flanged Hex Bolt 17
77 Canister Bracket 1
78 Carbon Canister Stopper Plate 1
79 Canister Bracket 1
80 Carbon Canister Assembly 1
81 Canister Tube 1
82 Canister Tube 1
83 Clamp 1
84 Socket Head Screw 2
85 Flanged Hex Bolt 6
86 Cylinder Head Cover Assembly 1
87 Breather Tube 1
88 Cylinder Head Cover Gasket 1
89 Rocker Shaft Bumper 1
90 Air Deflector 1
91 Flanged Hex Bolt 4
92 Stud 2
93 Outlet Gasket 1
94 Hex Nut M8 2
95 Valve Rocker Assembly 1
96 Pin Clip 2
97 Valve Rocker Shaft 2
98 Throttle Handle Assembly 1
99 Locating Pin 2
100 Cylinder Head Gasket 1
101 Cylinder Head 1
102 Spark Plug 1
103 Stud 2
104 Carburetor Gasket 1
105 Carburetor Insulating Pad 1
106 Carburetor Gasket 1
107 Carburetor 1
108 Carburetor Gasket 1
109 Air Filter 1
110 Manual Starter Assembly 1
111 Clamp 1
112 Oil Tube 1
113 Outlet Pipe 1
114 Governing Spring 1
Parts List and Diagram
Parts List
