14 - UPGRADING YOUR COMPUTER
Graphic board
The computer contains one or two Graphic boards
installed in the PCIE x16 slots. The detail
configuration will be differed by different models.
Removing the Graphics board
1.
Perform the
Pre-installation instructions on
page 2
.
2.
Disconnect the power cables from the
graphics board.
3.
Remove the three screws that secure the
graphics board to the chassis.
To Next Page
