INSTALLATION
Proper installation is the responsibility of the
installer.
Product failure due to improper installation is not
covered under the Warranty.
CHASSIS INSTALLATION
Units are shipped without a sleeve. In applications
where uni t i s a repl acemen t , i t is recom m end ed t hat a
approved PTAC sleeve.
Thes e unit s can ret ro fi t General Elect ri c, Amana,
Trane, and F riedrich sleeves/grilles (be sure outdoor
grille is installed on the sleeve). See Table 3 for
details in same instance use baffle kit.
For any sleeve retrofit applications, be sure that the
foam seal s (fact ory--ins t al l ed on t he tu be sh eet s )
provide a good seal between the grille and outdoor
coil tu be s heet s . Thes e foam seal s p rov i d e a barri er t o
separate outdoor coil leaving air from mixing with
the outdoor incoming air (known as air
recirculation).
UNIT DAMAGE AND/OR OPERATION HAZARD
Failure to follow this caution may result in equipment
damage or improper operation.
For retrofit applications, foam seals on outdoor coil tube
sheets must make a seal between the coil and the grille or
loss of performance and premature damage to the major
components can result.
CAUTION
!
Table 3—Retrofit W all Sleeves
Manufacturer
Wall Sleeve Part Number
General Electric Metal Sleeve RAB71
Plastic Sleeve RAB77
Amana Metal Sleeve WS900B
Trane Metal Sleeve SLV149
F riedrich T --- S e r i e s M e t a l 1 1
1/2
--- i n . D e e p W a l l
Sleeve*
Standard Depth Wall Sleeve
16 X 42 X 13
3/4
--- i n . P X W S
* FR---SLEEVE ---EXT accessory is required for retrofit into Friedrich
(T---Series) wall sleeves.
INDOOR
COIL
DISCHARGE
GRILLE
WIRE SCREEN
OUTDOOR
ORIFICE
COIL
TUBE
SHEETS
INDOOR-AIR
INLET
FILTERS
ACCESSOR
Y
WALL
SLEEVE
ACCESSOR
Y
OUTDOOR
GRILLE
Fig. 4 – Unit Components
FRONT
PANEL
BASEPAN
To Next Page
