4
Packaged and Split Rooftop Ventilator
Product Overview
A horizontally congured Dedicated Outdoor Air unit
designed for installation outdoors. The unit is designed
to replace air that is exhausted from the building and
also heat and cool, as needed. The air volume produced
by the unit is constant, but can be optionally modulated
to provide a variable air volume (VAV).
Cooling
Units have the following cooling options available:
• Packaged DX
• Split DX
Units with packaged DX are shipped fully charged with
refrigerant and are ready for operation upon arrival.
Heating
There are three different optional heat sources that can
be ordered for this unit:
• Indirect gas-red furnace with one or two sets of
heat exchangers
• Electric heat with innitely variable SCR control
• Hot water coil (Installed in furnace section)
Airow Arrangement
The unit is capable of Constant Air Volume (CAV),
Variable Air Volume (VAV), 100% Outdoor Air.
Safety Listing
Models are listed per ANSI/UL 1995, Heating and
Cooling Equipment and are ETL Certied.
Models and Capacities
Model Cooling Capacity
Packaged DX
MP-1-1/MPE-1-1 5 to 15 tons
MP-2-1/MPE-2-1 15 to 30 tons
MP-4-0/MPE-4-0 20 to 45 tons
Split DX
MPF-1-1 5 to 12 tons
MPF-2-1 10 to 20 tons
Supplemental Installation, Operation and
Maintenance Manuals
Refer to the following Manufacturer Installation,
Operation and Maintenance Manuals for additional
information:
• Indirect Gas-Fired Heat Modules
• Microprocessor Controller
• M-Net Connection
For information on Service and installation Operation
manual please refer to the manuals in the Outdoor
equipment.
• PUHY-P96T/YKMU
• PUHY-P144T/YKMU
• PUHY-P192T/YSKMU
• PUHY-P240T/YSKMU
© 2017 Mitsubishi Electric US, Inc.
