STEP 7
Estimated Time: 5 minutes
Using JCB connectors, and the Allen Key provided, attach
each lower stabilizer (B4), one at a time, to both inner gables
Identifying the Lower Stabilizer
The screw hole is at the top, close to the finished edge
B4
B4
IMPORTANT
Finished edge
If you have any difficulty tightening the JCB connector,
use a screwdriver to adjust the JRN nut to make sure
the hole is facing the opening for the connector
JCB
Connector
JRN
Nut
