4.0 Meet the StudioLive RM32AI and RM16AI
PreSonus
®
StudioLive
™
RM32AI/RM16AI
Visual Quick Start Guide
4.0 Meet the StudioLive RM32AI and RM16AI
Front
LevelLevel
32312 323130292726252423222120191817
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32
RightLeft
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
32 channel x 25 bus digital mix core
with 32 remote XMAX preamps
USB
STUDIOLIVE RM32
28
-80
+6
-80
+6
Cue
Mute
All
Meters
+48V
R
L
1
2
2
3
4
6 9 10 1211 13
7
85
1. Mix outputs
2. Microphone inputs
3. USB port (supports rmware updates and Wi-Fi dongle)
4. Power/status indicator
5. Input signal/clip/+48V indicators
6. +48V meters mode button
7. Mute All button
8. Headphone source selection buttons
9. Headphone level knob
10. Headphone output
11. Tape input
12. Main Mono output and trim knob
13. Main Left/Right outputs and trim knob
