Pressure Systems, Inc.
Model 9116 User’s
Manual
Page 103
www.PressureSystems.com
Note
It must be emphasized that printed circuit boards in Model 9116
module are field
replaceable
, but are NOT field
repairable
.
Figure 5.1a
Model 9116 Top Plate
