Pressure Systems, Inc. Model 9116 User’s Manual
Page 130 www.PressureSystems.com
Appendix E
Model 9116 Range Codes
The following range codes are stored in each DH200 pressure transducer. The range code of
each transducer can be read through the Read Internal Coefficient (‘u’) command. Standard
Range Codes are shown in Bold and Italics.
Range Code Full Scale Pressure Minimum Calibration
Pressure
1 0.360 psi (10" Water Column) -0.360 psig
2 0.720 psi (20" Water Column) -0.720 psig
3 1 psid -1.0 psig
4 2.5 psid -2.5 psig
5 5 psid -5 psig
6 10 psid -5 psig
7 15 psid -5 psig
8 30 psid -5 psig
9 45 psia 0 psig
10 100 psia 0 psig
11 250 psia 0 psig
12 500 psia 0 psig
13 600 psia 0 psig
14 300 psia 0 psig
15 750 psia 0 psig
16 10 psid -10 psig
17 15 psid -12 psig
18 30 psid -12 psig
19 45 psid -12 psig
20 20 psid -12 psig
21 20 psia 0 psig
22 15 psia 0 psig
