BodyGuardian One – Instructions for Use 13
1. Unplug the ECG lead set cable connection from the BodyGuardian One to disconnect
the lead wires and pause monitoring.
2. Unsnap the lead from the old electrode, and then snap the lead to a new electrode.
3. Remove the adhesive backing from the new electrode.
4. Attach the new electrode an inch away from the old electrode. Make sure the
electrodes are attached within the following placement zone:
5. Peel the old electrodes off the skin. Use soap and water to reduce irritation and to
remove any residue. Dispose of the electrodes.
6. Plug the ECG lead set cable into the monitor to resume monitoring.
Always unplug the cable before changing out electrodes to prevent ECG data loss
All five leads must remain securely attached to chest during the prescribed
monitoring period; this ensures that the device will trigger events properly.
